Net Bag Clipping Machine
This Net Bag Clipping Machine uses tubular net material, receives the product from the dosing equipment above, clips and cuts the net bag to create a mesh net package, and output finished bags. It can also attach a tag/label to the net package with optional device Label Applicator & Printer.

The Net Bag Clipping Machine is ideal for various products such as:-
* Agricultural products like potatoes, tomatoes, carrots, peppers, onions, garlics, gingers, peas, peanuts, chest nuts, wallnuts, Hazelnuts etc.
* Fruits like lemons, oranges, grapefruits, apples, pomegranates, mangos, dates, kiwifruits etc.
* Multi-parts toys and many more.


You can choose to have Linear Weigher, Multihead Weigher and Belt Type weighing Machine or Counting Feeder for dosing different products down to the Clipping Machine.

  • Main Features
  • Technical Data
  • Video
  • FEATURES
    * Stainless Steel contact parts for food hygien.
    * User friendly Touch Screen and PLC control.
    * Very stable running, very efficient and outputs even sized packages.
    * Product in net bags are well displayed to consumers.
    * Alternation of Tubes is motorized, very easy and efficient.
    * Metal Clip is from a strip band cassette which can be replaced easily when empty.

    OPTIONS:
    * Label Applicator
    * Printer for Labels
    * Net Material Loading Device (save your time greatly to load the net material on to the tube)

  • Model OVA-21
    Tube Diameter 200mm
    Speed Up to 35 ppm
    Weight Range 0.5 – 5 KG (depends on the products)
    Power supply AC 380V 50Hz, 3 phase (or customized)
    Power Rate 2.6 KW
    Air Consumption 1.5 m3/h, 0.6Mpa
    Net/Gross Weight 425KG / 650KG
    Overall Dimensions 1840L x 720W x 2010H mm
    Packing Dimensions 1600L x 1100W x 2020H mm

    Note: Product data are subject to change without notice. Always verify the latest information with us before purchase.
